Specifications |
|
|
Model |
852C+ |
|
Measuring range (Flat steel) |
1.2mm~300.00mm |
|
Probe frequency |
5MHz |
|
Accuracy |
± (1% H+ 0.1) mm |
|
Resolution |
0.1mm |
|
Pipe limit |
Φ20 x 3.0mm |
|
Sound velocity range |
1000~9000 m/s |
|
Sound velocity accuracy |
>20mm: 5% / ,20mm: ±1mm/H*100% |
|
Subject surface temperature |
0~40 °C |
|
Features |
|
|
Model |
852C+ |
|
Auto power off |
√ |
|
Low battery indication |
√ |
|
Max./Min./Average value |
√ |
|
High and low limit set up |
√ |
|
Sound velocity setting |
√ |
|
Sound velocity choosing |
√ |
|
Continuous measurement mode |
√ |
|
Benchmark calibration |
√ |
|
Single point or multi-points judge mode |
√ |
|
Interface |
USB |
|
LCD with color display |
With adjustable backlight |
|
Data store |
512 group |
|
General Information |
|
|
Model |
852C+ |
|
Power supply |
9V 6F22 battery |
|
Product weight |
300g |
|
Product size |
165x55x35mm |
|
Standard accessories |
Battery, manual, tool box, USB cable, 5Mhz probe, lanyard |
